Geometry - Road (HR)
45 | 48 | 51 | 54 | 57 | |
---|---|---|---|---|---|
Reach | 367 | 379 | 382 | 391 | |
Stack | 510 | 523 | 545 | 561 | |
Top Tube (effective) | 510 | 530 | 543 | 565 | |
Seat Tube C-T | 441 | 473 | 502.5 | 535 | |
Seat Tube C-C | 420 | 453 | 485 | ||
Head Angle | 71 | 72.1 | 73 | 74 | |
Seat Angle | 74.3 | 74.4 | 73.5 | 73.5 | |
Head Tube | 97.5 | 107.5 | 127 | 140 | |
Chainstay | 408 | 408 | 410 | 410 | |
Wheelbase | 974 | 977 | 980 | 983 | |
Front Centre | 577 | 579 | 580 | 595 | |
Standover | 705 | 743 | 760 | 790 | |
BB Drop | 72 | 70 | 70 | 70 | |
Fork Length (A2C) | 373.5 | 373.5 | 373.5 | 373.5 | |
Tire Width (max) | 32mm | 32mm | 32mm | 32mm | 32mm |
Stem Length | 90mm | 90mm | 90mm | 100mm | 110mm |
Crank Length | 170mm | 170mm | 170mm | 172.5mm | 175mm |
Handlebar Width | 380mm | 380mm | 380mm | 400mm | 420mm |
